Details
TRUE CYCLING EXPERIENCE.
Not every cyclist wants to push their body to the extreme, trying to fit on a bike that was designed for the pro peloton, so we went back to the drawing board for the Pinarello X and designed a new geometry that offers all-day comfort without renouncing our legendary performance DNA. Thanks to a combination of specifically-selected materials, unique geometry, and a truly innovative rear-end, the Pinarello X strikes the perfect balance between reactivity, performance, and comfort.
CARBON T600
UD
A comfort-optimized carbon fiber structure with an unidirectional finishing that absorbs all road vibrations for a pleasurable and comfortable ride.
ASYMMETRIC FRAME
PINARELLO X
For first Pinarello understood that, while the thrust applied to both pedals is the same, the pull on the chain applies to the right side only. For this reason, all frames are optimized to compensate for these unbalanced forces.
ONDA
FORK
A distinctive Pinarello Technology since 2000. The shape of the fork delivers precise turning abilities, stability, and reduction of longitudinal and lateral shocks.
FLEX
STAYS
An exclusive Pinarello design that absorbs vibrations without reducing the responsiveness of the rear triangle
CE: SEAT TUBE CENTER - END, CC: SEAT TUBE CENTER - CENTER, L: TOP TUBE CENTER - CENTER, A[°]: SEAT TUBE ANGLE, B[°]: HEADTUBE ANGLE, P: CHAINSTAY, T: HEADTUBE, D: BB DROP, R: FORK RAKE , G: FORK HEIGHT, REACH, STACK
CE | CC | L | A [°] | B [°] | P | T | D | R | G | Reach | Stack |
---|---|---|---|---|---|---|---|---|---|---|---|
425 | 430 | 492 | 75.25 | 70 | 415 | 125 | 67 | 52 | 373 | 341.9 | 527.5 |
450 | 460 | 509 | 74.5 | 70.5 | 415 | 130 | 72 | 52 | 373 | 352.1 | 539.2 |
470 | 490 | 525 | 74 | 71 | 415 | 142 | 72 | 52 | 373 | 361.9 | 552.4 |
495 | 515 | 536 | 73.75 | 71.5 | 415 | 151 | 72 | 47 | 373 | 368.5 | 564.4 |
510 | 530 | 545 | 73.5 | 72 | 415 | 161 | 72 | 47 | 373 | 372.5 | 575.8 |
525 | 545 | 555 | 73.25 | 72.25 | 415 | 173 | 72 | 47 | 373 | 376.7 | 588.2 |
540 | 560 | 565 | 73 | 72.5 | 415 | 187 | 72 | 47 | 373 | 380.2 | 602.4 |
560 | 580 | 577 | 72.75 | 72.5 | 415 | 211 | 67 | 47 | 373 | 384.1 | 620.3 |
590 | 600 | 590 | 72.5 | 72.5 | 415 | 232 | 67 | 47 | 373 | 388.1 | 640.4 |
Specs
Frame | Torayca T600 UD, internal cable routing, Italian BB, UCI approved |
---|---|
Seat clamp | fsc frontal seat clamp |
Axles | MOST Ultralight Custom Axle 12x100 & 12x142, Tool-free removal |
Bottom Bracket | shimano 105 |
Crankset | shimano 105 |
Front Derailleur | shimano 105 |
Cassette/Freewheel | shimano 105 |
Chain | shimano 105 |
Brakes | Shimano 105 2 pistons, 160mm rotor Shimano 105 2 pistons, 160mm rotor |
Handlebars | Jaguar XA Aero TiCR |
Tape/Grips | Tiger Aero Alu TiCR |
Seatpost | Pinarello Aero Seatpost |
* Subject to change without notice.
Part Numbers
Option | MPN | Store SKU |
---|---|---|
Pearl White / 43cm | D1666610149-00019 | |
Pearl White / 46cm | D1666610149-00020 | |
Pearl White / 49cm | D1666610149-00021 | |
Pearl White / 51.5cm | D1666610149-00022 | |
Pearl White / 53cm | D1666610149-00023 | |
Pearl White / 54.5cm | 01.21.11.3336 | |
Pearl White / 56cm | D1666610149-00025 | |
Pearl White / 58cm | D1666610149-00026 | |
Pearl White / 60cm | D1666610149-00027 | |
Shiny Black / 43cm | D1666610149-00028 | |
Shiny Black / 46cm | D1666610149-00029 | |
Shiny Black / 49cm | D1666610149-00030 | |
Shiny Black / 51.5cm | D1666610149-00031 | |
Shiny Black / 53cm | D1666610149-00032 | |
Shiny Black / 54.5cm | 01.21.11.3335 | |
Shiny Black / 56cm | D1666610149-00034 | 210000148457 |
Shiny Black / 58cm | D1666610149-00035 | |
Shiny Black / 60cm | D1666610149-00036 |
